鉑金硫化硅膠編織軟管BP20系列

東莞市格雷特硅膠制品有限公司

鉑金硫化硅膠編織軟管BP20系列

Platinum vulcanization silicone braided hose BP20

產品應用：

鉑金硫化(hua)硅膠軟BP20系列廣泛用于高低溫(wen)食(shi)品(pin)(pin)乳制品(pin)(pin)和食(shi)品(pin)(pin)用油類、化(hua)妝品(pin)(pin)、化(hua)工(gong)和制藥行業和生物工(gong)程用的液體或(huo)半液體流體的產品(pin)(pin)輸送，

（如牛奶，果汁；食品機械設備用(yong)連(lian)接(jie)管(guan)；酒(jiu)類用(yong)連(lian)接(jie)導管(guan)；醫藥設備連(lian)接(jie)管(guan)路等,同時(shi)可配有(you)3A，SMS，DIN，CLAMP快(kuai)速(su)接(jie)頭）

軟管結構：

硅膠軟管采用聚脂編織和鉑金硅膠組合而成。

標準長度為20米每卷，同時我們也可以根據客戶的要求生產規定的尺寸和長度。

軟管優點：

鉑金(jin)硫化(hua)硅(gui)膠軟BP20系列(lie)：

——工作溫度范圍‘-60oC / +180oC (-76oF / +356oF)在(zai)短時(shi)間內可(ke)達(da)到  220oC (392oF)

——內壁光滑清潔(jie)，易清洗(xi)不粘水，用清洗(xi)物(wu)清洗(xi)后(hou)不附著任何殘留物(wu)，可(ke)采用高溫(wen)高壓蒸(zheng)汽消毒和滅菌。

——無嗅、無味,完全無毒，不含任(ren)何塑化(hua)劑和(he)添加劑成分。完全符合食(shi)品FDA和(he)生物醫用級USP VI的(de)要求。

——這(zhe)些管(guan)通常是半透明的(de)，可以(yi)觀察(cha)到(dao)流體的(de)動向。我們也可根據(ju)客戶所需顏色來(lai)訂制。

品質認證：

——鉑金硅膠軟管通過美國(guo)FDA 21 CFR 177.2600(食品和藥物管理局)食品級認證。

——歐盟指令2008/95 / ECC的限制使用(yong)某些有害物質(RoHS)認可。

——鉑金硅膠軟管符合(he)ISO10993,NSF51和歐洲藥典3.1.9的要求。

Product application:

Widely used for transportation or delivery of low temperature food, cosmetics, chemical materials or the fluid or semi liquid fluid of pharmaceutical industry and biological engineering.(such as milk, fruit juice; the connection hoses used on food machinery liquor equipment; oil production equipment and medical equipment,and can be equipped with 3A, SMS, DIN, CLAMP quick connector).

Product description:

-Silicone hose is made by the polyester braiding and platinum silicone. Widely used in the industry of liquid and semi fluid food, medicine and cosmetic products, bio engineering.

-Standard length is 20 meters per roll, and we can produce the specified size and length according to customer requirements.Our hose products pass the certification of the United States FDA grade and Class VI USP and German BFR.

Product characteristics:

-The working temperature range of -60 to +180 degree Celsius (-76 to +356 degree Fahrenheit) in a short period of time can reach 220 degrees Celsius (392 degrees Fahrenheit)

-With a good bend, the inner wall is smooth and clean, easy to be washed, no water sticking,

After cleaned by cleaning materials, no residue remained. The steam disinfection and sterilization can be done under high temperature and high pressure.

-Odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully comply with the requirements of food FDA and biological medical grade VI USP.

-These tubes are usually translucent and the movement of fluid inside can be observed. The hose color can be customized according to customer's needs.
