鉑金硫化硅膠編織軟管BPB20系列

東莞市格雷特硅膠制品有限公司

鉑金硫化硅膠編織軟管BPB20系列

 Platinum  vulcanization silicone braided hose BPB20

產品應用：

鉑金硫化(hua)硅膠軟BPB20系列廣(guang)泛用于(yu)高低溫食(shi)品乳制品和食(shi)品用油類、化(hua)妝品、化(hua)工(gong)和制藥行業和生物工(gong)程用的(de)液體或半液體流體的(de)產品輸送，（如牛(niu)奶，果汁；食品機械設備用(yong)連(lian)(lian)接(jie)(jie)管；酒類用(yong)連(lian)(lian)接(jie)(jie)導(dao)管；醫藥(yao)設備連(lian)(lian)接(jie)(jie)管路等,同時(shi)可(ke)配有3A，SMS，DIN，CLAMP快速接(jie)(jie)頭）

產品描述：

食品級硅膠軟管采用(yong)聚脂編織和鉑(bo)金硅膠(jiao)組合而(er)成。廣泛的應用(yong)于通過食品，醫藥及化妝(zhuang)用(yong)品，生物工程的液體(ti)(ti)和半流體(ti)(ti)。

標準長(chang)度為(wei)20米每卷，同時我們(men)也可以(yi)根據(ju)客(ke)戶(hu)的要求生產(chan)(chan)規定的尺寸(cun)和長(chang)度，膠管產(chan)(chan)品通過美國(guo)FDA級和USP Class VI和德國(guo)BFR認證(zheng)。

產品特性：

鉑金(jin)硫(liu)化(hua)硅膠軟BPB20系列：

——工作溫度(du)范圍‘-60oC / +180oC (-76oF / +356oF)在短(duan)時間內可達到  220oC (392oF)

——具有很好(hao)彎曲(qu)性，內壁(bi)光(guang)滑清潔(jie)，易清洗(xi)不粘水，用(yong)清洗(xi)物(wu)清洗(xi)后不附著任(ren)何殘留物(wu)，可采用(yong)高溫高壓蒸汽消毒和滅菌。

——無(wu)嗅、無(wu)味,完全無(wu)毒，不(bu)含任何塑(su)化劑和添加劑成分。完全符合(he)食品FDA和生物醫用級USP VI的要求。

——這些管通常是半(ban)透明的(de)，可以觀察到流體的(de)動向(xiang)。我們也可根據客戶所需(xu)顏色來訂制。

品(pin)質認證：

——鉑金硅膠軟管通過美國FDA 21 CFR 177.2600(食品和藥物(wu)管理局)食品級認證。

——鉑金硅膠(jiao)軟管通(tong)過德國BfR零件 XV標準(zhun)認證和LFBG認證。

——鉑金硅膠軟管(guan)符(fu)合通過美(mei)國醫(yi)用USP Class VI級標準認(ren)證(zheng)。

——鉑(bo)金(jin)硅膠管依照歐盟指令2008/95 / ECC的限制使用(yong)某些有害(hai)物質(zhi)(RoHS)認可(ke)

——鉑金硅(gui)膠軟管(guan)符(fu)合ISO10993,NSF51和歐洲藥(yao)典(dian)3.1.9的要求。

Product application:

Widely used for transportation or delivery of low temperature food, cosmetics, chemical materials or the fluid or semi liquid fluid of pharmaceutical industry and biological engineering.(such as milk, fruit juice; the connection hoses used on food machinery liquor equipment; oil production equipment and medical equipment,and can be equipped with 3A, SMS, DIN, CLAMP quick connector).

Product description:

-Silicone hose is made by the polyester braiding and platinum silicone. Widely used in the industry of liquid and semi fluid food, medicine and cosmetic products, bio engineering.

-Standard length is 20 meters per roll, and we can produce the specified size and length according to customer requirements.Our hose products pass the certification of the United States FDA grade and Class VI USP and German BFR.

Product characteristics:

-The working temperature range of -60 to +180 degree Celsius (-76 to +356 degree Fahrenheit) in a short period of time can reach 220 degrees Celsius (392 degrees Fahrenheit)

-With a good bend, the inner wall is smooth and clean, easy to be washed, no water sticking,

After cleaned by cleaning materials, no residue remained. The steam disinfection and sterilization can be done under high temperature and high pressure.

-Odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully comply with the requirements of food FDA and biological medical grade VI USP.

-These tubes are usually translucent and the movement of fluid inside can be observed. The hose color can be customized according to customer's needs.

Quality certification:

-Platinum silicone hoses pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.

-Platinum silicone hoses pass the German BFR parts XV standard certification and LFBG certification.

-Platinum silicone hose is in accordance with the United States Class VI USP grade standard certification.

-Platinum silicone hose is in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.

-Platinum silicone hose is in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
