90度硅膠彎管軟管EB90

90度硅膠彎管軟管EB90

90 degree angle silicone elbow EB90

產品應用：            ;

本產品推(tui)薦應用于在高溫高壓(ya)時，可以過熱空氣和熱水，具有良好的(de)(de)耐(nai)溫性和耐(nai)腐(fu)性. 主要應用于公(gong)共汽(qi)車(che)，拖車(che)和一些特(te)殊(shu)工況下，同時可以應用于汽(qi)車(che)發動(dong)機(ji)。可做為汽(qi)車(che)，貨柜車(che)，公(gong)共汽(qi)車(che)發動(dong)機(ji)的(de)(de)冷(leng)卻(que)水管

Product application:

This product is especially recommended for hot air and hot water going through under high temperatures and high pressures with good temperature and corrosion resistance. At high temperatures, it can be used in vehicles and in the industrial sector.

It can be used in cooling and heating systems in buses, coaches, lorries and industrial vehicles, cooling systems in the cogeneration units and marine engines, and transport of high temperature fluids in general industry.

It is recommended for connections in areas with limited space.

產品特點：

-具有很好的壓縮

-組裝(zhuang)過程中具有(you)良好的彎曲性和柔(rou)軟性能。

-內外表面(mian)光滑，可以做藍色，紅色和(he)黑色，同(tong)時還可以是可以根據客戶的要求來定做顏色和(he)不(bu)同(tong)規格的長度(du)。

-具有(you)良好的(de)耐溫性能，工作溫度為-60 oC (-75 F) to +180oC (356 F），短時(shi)間的(de)工作溫度可以達到(dao) 200oC (392 F)

一般(ban)長(chang)度為100*100,150*150,200*200MM,如有特殊要(yao)求(qiu)可以根據客戶的要(yao)求(qiu)來定做.

---耐(nai)臭氧性,抗UV性能(neng)(neng)和耐(nai)老(lao)化性能(neng)(neng).

Product features:

- with excellent compressibility

- good bendability and flexibility during assembly.

- outer and inner hose surface is smooth with choices of blue color, red color and black color.At the same time, the color and length of this elbow can be custom made according to the customer's needs.

- with good temperature resistance, operating temperature from 60 degrees C (- 75 F) to + 180 degrees C (+356 F).In short time, the temperature can reach 200 degrees C (+392 F).

-normal length is 100*100mm, 150*150mm, 200*200mm. And, the length can be customized according to customer's needs.

-Oxidation resistance, anti UV performance and aging resistance.

符合標準：

1.產品符合SAE J20R1 Class A的標準(zhun)

2.硅膠軟(ruan)管(guan)符(fu)合歐洲(zhou)EU 2002/95/ECC 環保RoHS認證標準(zhun)。

Regulations:

?comply with the J20R1 Class A SAE standard

-comply with the European 2002/95/ECC RoHS environmental EU certification standards
