硅膠鋼絲軟管SP70

東莞市格雷特硅膠制品有限公司

鋼絲硅膠軟管SP70

wire silicone hose SP70

注:1.標準生產長(chang)度為6米（特(te)殊可(ke)訂做(zuo)10米）。可(ke)以做(zuo)切短。其它的內(nei)徑要求可(ke)以根(gen)據客戶的要求來(lai)訂制(zhi)。

2.在我(wo)們在參數(shu)表中測試是依照(zhao)常(chang)溫(wen)，標準大氣壓(ya)狀態。當壓(ya)力不變時(shi)，溫(wen)度每(mei)上升幅度100度，壓(ya)力會下(xia)降百分之15。

REMARKS:

1,Test conditions: tested under normal temperature and pressure state(room temperature is 20 degrees Celsius),

When the pressure is constant, the temperature rise by 100 degrees, the pressure will drop by 15%.

2, Standard length is 6 meters or especially 10 meters and we can customize the hose length according to customers' needs.

應用：

用(yong)于高壓(ya)環境，出眾的抗腐蝕(shi)性，在工作溫度(du)下，機械性能不隨(sui)溫度(du)變化。可以通過高溫液體和半固態(tai)流體。主要用(yong)于汽車(che)，拖車(che)，貨車(che)，等車(che)。



性能：    ;

強耐臭氧,耐防凍液和(he)防銹液

不易硬化(hua)，良(liang)好(hao)的(de)壓縮特性

產品壽命(ming)長，減少保養(yang)問(wen)題

內(nei)層：甲基乙烯(xi)基硅(gui)橡膠管，含不銹鋼螺旋線圈和(he)2層聚酯加強(qiang)筋。

內表面：藍色，光滑。

外表面：藍色，光滑。

耐溫：-50°C(-122F) to +180°C (356F)，在短時間可以達(da)到 +200°C (392F)，同(tong)時具有良好的真空度(du)0.91 bar (12.3psi)

Product applications:

Used in high pressure enviroment with excellent corrossion resistance. Under working temperature, the mechanical performance will not change with temperature.

High temperature liquid and semi solid fluid can flow through. Mainly used on auto, trailers, trucks and so on.



Product properties:

Strong ozone resistance, highly resistant to anti-freezing liquid and auti-rust liquids.

Uneasily hardening, good compressiblity, long product life and reducing maintenance problems.

inner layer:methyl vinyl silicone rubber hose,including spiral stainless steel wire and 2 layers of polyester reinforcement.

inner surface: blue and smooth.

outer surface: blue and smooth.

working temperature from -50 degrees Celsius (-122 degrees Fahrenheit) to +180 degrees Celsius (+356 degrees Fahrenheit).

In short time, the temperature can reach 200 degrees Celsius (+392 degrees Fahrenheit).

with very good vacuum rate as 0.91 bar(12.3psi)
