鉑金硫化硅膠鋼絲軟管FP33

產(chan)品(pin)應用：

特(te)別推薦(jian)用(yong)于運輸(shu)或(huo)輸(shu)送高(gao)(gao)低溫食(shi)品、化妝(zhuang)品、化工(gong)和(he)制(zhi)藥行業和(he)生物工(gong)程用(yong)的(de)液(ye)體或(huo)半液(ye)體流(liu)體，同時可應用(yong)于特(te)殊高(gao)(gao)溫高(gao)(gao)壓狀態。

如(ru)抽(chou)吸食品類乳制品；食品機械設備用連接管(guan)；酒類用連接導(dao)(dao)管(guan)；油(you)類設備抽(chou)吸用的(de)連接管(guan)，醫藥設備連接管(guan)路、導(dao)(dao)管(guan)等

產品(pin)結構：

編(bian)織：五層夾(jia)布網紋編(bian)織，中間采用不銹鋼(gang)絲(si)編(bian)織，內襯不銹鋼(gang)絲(si)

鋼絲：采用(yong)304不銹鋼絲，鋼絲間距為6MM，具有3倍(bei)之普(pu)通鋼絲管的(de)壓力

產品特性：

——工作溫度(du)范圍‘-60oC / +180oC (-76oF / +356oF)在短(duan)時間內可達到(dao)  220oC (392oF)

——承正負壓(ya)能力強，用清洗物清洗后不附著任何(he)殘(can)留物，可采用高溫高壓(ya)蒸汽消毒和滅菌(jun)。

——無嗅、無味,完全(quan)無毒，不含任何塑化劑和添加劑成分。完全(quan)符合食品(pin)FDA和生物(wu)醫用級USP的(de)要求(qiu)。

——產品經過高溫(wen)180oC*4小時(shi)高溫(wen)硫化后，不分(fen)產生(sheng)任何分(fen)解物，具體參考數據(ju)表。

配套接頭：

TC接(jie)(jie)頭（直通快(kuai)速接(jie)(jie)頭316L），SMS接(jie)(jie)頭，DIN快(kuai)接(jie)(jie)，CLAMP，CLOCK，J螺紋接(jie)(jie)頭，等材質為304或316L任客戶挑(tiao)選(xuan)。

品質認證(zheng)：

——鉑金硅膠(jiao)軟管(guan)通過美國FDA 21 CFR 177.2600(食(shi)(shi)品和藥(yao)物管(guan)理局)食(shi)(shi)品級認證。

——鉑金硅膠軟(ruan)管通過(guo)德國FDA/BfR零(ling)件 XV標(biao)準認證(zheng)和LFBG和BGVV標(biao)準認證(zheng)。

——鉑金硅(gui)膠軟(ruan)管符合通過美國醫用(yong)USP Class VI級標準認證(zheng)。

——鉑金硅(gui)膠管依照歐(ou)盟指(zhi)令2008/95 / ECC的限制使用某些有害物質(zhi)(RoHS)認可。

Product application:

Widely used for transportation or delivery of low temperature food, cosmetics, chemical materials or the fluid or semi liquid fluid of pharmaceutical industry and biological engineering.

(such as the suction of food or dairy products; the connection hoses used on food machinery

liquor equipment; oil production equipment and medical equipment, etc.)

Product structure:

Weaving: 5 layers of cloth woven mesh

Steel wire:Layer of 304 stainless steel wire and the spacing of double layer of steel wire is 4mm and the pressure is 3 times more than the one of the ordinary wire hose.

Product characteristics:

-The working temperature range: -60 to +180 degrees Celsius (or -76 to +356 degrees Fahrenheit) and it can reach 220 degrees Celsius (or 392 degree Fahrenheit) in a short period of time

-With a good bend, the inner wall is smooth and clean, easy to be washed, no water sticking,

After cleaned by cleaning materials, no residue remained. The steam disinfection and sterilization can be done under high temperature and high pressure.

-Odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully comply with the requirements of food FDA and biological medical grade USP.

-Product will not produce any decomposition after high temperature of 180 degrees Celsius * 4 hours of high temperature Vulcanization with strong bearing capacity of negative and positive pressure.
