鉑金硫化編織軟管BG20R

注：長(chang)度：標(biao)準最長(chang)長(chang)度為50米，如需(xu)更長(chang)長(chang)度，顏色(se)可以根據(ju)客戶(hu)要求(qiu)來訂，請來電咨詢(xun)

應用：

鉑金(jin)硫化硅膠軟管(guan)采用(yong)中(zhong)間玻(bo)璃(li)纖維(wei)編織，應用(yong)于(yu)低壓(ya)輸送液(ye)體(ti)，可進(jin)行SIP和CIP清洗(xi)，具有很好的抗壓(ya)能力。產品通(tong)過(guo)大量的物(wu)理，化學和生物(wu)檢測達到(dao)FDA CFR 177.2600

不建議用于真空環境；

產品特性：

鉑金硫(liu)化(hua)硅(gui)膠軟BG20系列(lie)

——工作溫度范圍‘-60oC / +200oC

——具(ju)有極好彎(wan)曲性，可采(cai)用高(gao)溫高(gao)壓蒸汽消毒SIP清洗和高(gao)溫高(gao)壓清洗CIP。

——無嗅、無味,完全無毒(du)，不(bu)含任(ren)何塑化劑和添加(jia)劑成(cheng)分

——這些管通常是半透明的(de)，可以觀察(cha)到流體的(de)動向。我們也(ye)可根據(ju)客戶所需顏色來訂(ding)制(zhi)。

品(pin)質認證(zheng)：

——鉑金(jin)硅膠(jiao)軟管通過(guo)美國(guo)FDA 21 CFR 177.2600(食品(pin)和藥物(wu)管理局)食品(pin)級認證。

——歐盟指令2008/95 / ECC的使用某(mou)些(xie)有害物質(RoHS)認可(ke)。         ;

——鉑金硅膠軟管符合(he)ISO10993,NSF51和歐洲藥典3.1.9的要求。

Remarks:

Standard length: 50 meters or customized according to customer's special needs.

Product application:

The polyester weaving added in the middle for the platinum vulcanization silicone hose, which can be used to delivery the low pressure

liquid and to proceed with SIP cleaning and CIP cleaning. With good compression resistance and meet FDA CFR 177.2600 certificate after plenty of physical, chemical and biological testing.

Not recommended for vacuum environment.

Product characteristics:

-The working temperature range of -60 to +200 degree Celsius.

-With a good bend.high temperature and high pressure steam disinfection cleaning SIP and high temperature and high pressure cleaning CIP can be used.

-Odorless, tasteless, non-toxic, does not contain any additives and plasticizer.

-These tubes are usually translucent and the movement of fluid inside can be observed. The hose color can be customized according to customer's needs.

Quality certification:

-Platinum silicone hoses pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.

-Platinum silicone hoses pass the German BFR parts XV standard certification and LFBG certification.

-Platinum silicone hose is in accordance with the United States Class VI USP grade standard certification.

-Platinum silicone hose is in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.

-Platinum silicone hose is in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
