鉑金硫化硅膠軟管FU10系列

東莞市格雷特硅膠制品有限公司

金硫化硅膠軟管FU10系列

Platinum vulcanization silicone hose FU10

產品應用(yong)：

?高(gao)級飲料(liao)用(yong)軟管(guan)，特別(bie)適用(yong)于(yu)運送各種軟飲料(liao)和酒(jiu)精飲品，以及(ji)其他液體飲料(liao)如 啤酒(jiu)，果汁和飲用(yong)水。

?廣泛應用于(yu)啤酒廠、葡(pu)萄酒廠和(he)飲料(liao)廠。適用于(yu)吸入(ru)和(he)輸送應用。

產品描述：

材質：鉑金硅膠，SS304不銹鋼絲(si)，高溫聚脂纖維(wei)線

MAIN BENEFITS - 顯(xian)著特性

鉑金硫化硅膠軟管FU20系列

——工(gong)作溫度(du)范圍‘-60oC / +180oC (-76oF / +356oF)在短(duan)時間內可達到  220oC (392oF)

——具有很好彎曲性(xing)，耐真空性(xing)能好，可采(cai)用高(gao)溫高(gao)壓(ya)蒸汽消毒SIP清(qing)洗和(he)高(gao)溫高(gao)壓(ya)清(qing)洗CIP。

——無嗅、無味,完全無毒，不含任何(he)塑化劑和添(tian)加劑成分。完全符合食品FDA和生物醫用(yong)級USP VI的要(yao)求(qiu)。

——耐(nai)大氣侵蝕，耐(nai)老化，平滑，布狀表面(mian)。

品質認(ren)證：

——鉑(bo)金(jin)硅膠(jiao)軟管通過美國FDA 21 CFR 177.2600(食品(pin)和藥物管理局)食品(pin)級認(ren)證。

——鉑(bo)金硅膠(jiao)軟管(guan)通過德國BfR零件(jian) XV標準認證(zheng)和LFBG認證(zheng)。

——鉑金(jin)硅膠軟管符合通過美(mei)國醫用USP Class VI級標準認證。

Product application:

-Advanced beverage hoses.Especially suitable for deliverying all kinds of soft drinks and alcoholic beverages,

as well as other liquid beverages such as beer,fruit juices and drinking water.

-Widely used in beer plants, wine plants and beverage plants. Suitable for suction and and delivery.

Product discription:

Materials: Platinum silicone, SS304 stainless steel wire, high temperature Polyester fiber thread

Product characteristics:

-The working temperature range: -60 to +180 degrees Celsius (or -76 to +356 degrees Fahrenheit) and it can reach 220 degrees Celsius (or 392 degree Fahrenheit) in a short period of time

-With a good bend, vacuum resistance,used for high temperature and high pressure steam disinfection SIP cleaning and high temperature and high pressurecan cleaning CIP.

-Odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully comply with the requirements of food FDA and biological medical grade USP.

-atmospheric corrosion resistance, aging resistance, smooth cloth surface.

Quality certification:

-Platinum silicone hose passes the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.

-Platinum silicone hose passes the German FDA/BFR parts XV standard certification and LFBG and BGVV standard certification.

-Platinum silicone hose in accordance with the United States Class VI USP grade standard certification.
